Description
Spécifications physiques |
|---|
| A- -Flasque montage- -91.00 |
| E- -Trou de montage- -13.65 |
| E- -Trou de montage 2- -13.65 |
| B- -Distance lanceur- -15.50 |
| F- -Distance/arrière- -258.00 |
| G- -Distance/avant- -36.00 |
| H- -No. de dents- -12 |
| I- -B+- -M10 |
| N- -Type couronne- -Gr |
| O- -Distance mm- -142.30 |
| P- -Rotation- -Cr |
| R- -Longueur totale mm- -299.00 |
Spécifications électriques |
|---|
| Voltage- -12 |
| KW- -2.5 |
marque générique
remplace
| 113239- -CARGO- -CST40208AS- -CASCO |
| 12214- -EAI- -F042S00079- -UNIPOINT |
| 128000-8640- -DENSO- -MAV422080- -SIOM |
| 128000-8641- -DENSO- -S-8568- -DIXIE |
| 18197N- -WAI / TRANSPO- -STN3239- -KRAUF |
| 18424N- -WAI / TRANSPO- -STN9239- -KRAUF |
| 190.573.122- -PSH- -STR70101- -WOODAUTO |
| 20432802BN- -REAL- -UD16529S- -AS-PL |
| 20513034- -PRESTOLITE- -S6390S- -AS-PL |
| 228000-1610- -DENSO- -5040655- -MEAT & DORIA |
| 228000-1611- -DENSO- -STR6072- -ELECTROLOG |
| 246-25127- -DIXIE- -28100-17060- -TOYOTA |
| 254253- -KUHNER- -28100-17090- -TOYOTA |
| 28100-17010- -TOYOTA- -2810017061- -TOYOTA |
| 28100-17040- -TOYOTA- -2810017090- -TOYOTA |
| 6040208.0- -SANDO- -91-29-5316N- -WILSON |
| 88213839- -POWERMAX- -CGB-23039- -AINDE |
| 91-29-5316- -WILSON |
montage sur :
| Marque- -Modèle- -Type- -Année |
| TOYOTA- -Land Cruiser 3.0 TD GX 90 Custom 4WD- -[1KZ-T]- -01.1990-09.1991 |
| TOYOTA- -Land Cruiser 4.2 TD- -[1H-Z]- -01/01/90 |
| TOYOTA- -Land Cruiser 3.4 – — – 09.2002-08.2004 |
| TOYOTA- -Land Cruiser 4.2 TD- -[1HD-FT]- -03.1995-12.1997 |
| TOYOTA- -Land Cruiser 3.4- -[3B]- -01/01/81 |
| TOYOTA- -Land Cruiser 4.2 TD- -[1HD-T]- -01.1990-12.1997 |
| TOYOTA- -Land Cruiser 3.4- -[3B]- -01/01/82 |
| TOYOTA- -Land Cruiser 4.2 TD- -[1HD-T]- -10.1992-12.1997 |
| TOYOTA- -Land Cruiser 3.4- -[3B]- -01/01/83 |
| TOYOTA- -Land Cruiser 4.2 TD 100- -[1HD-FTE]- -01/01/98 |
| TOYOTA- -Land Cruiser 3.4- -[3B]- -01/01/84 |
| TOYOTA- -Land Cruiser 4.2 TD 90 4WD – — – 08.1999-08.2001 |
| TOYOTA- -Land Cruiser 3.4- -[3B]- -01/01/85 |
| TOYOTA- -Land Cruiser 4.2 TDi 24V 100- -[1HD-FTE]- -01.1998-07.2008 |
| TOYOTA- -Land Cruiser 4.5- -[1FZ-FE]- -01.1993-01.1995 |
| TOYOTA- -Land Cruiser 4.5- -[1FZ-FE]- -01.1996-01.1997 |
| TOYOTA- -Land Cruiser 4.5 24V- -[1FZ-FE] |
| TOYOTA- -Land Cruiser 3.4 Diesel- -[3B]- -08.1980-10.1984 |
| TOYOTA- -Land Cruiser 3.4 Diesel- -[3B]- -10.1981-08.1987 |
| TOYOTA- -Land Cruiser 3.4 Diesel- -[3B]- -11.1984-12.1996 |
| TOYOTA- -Land Cruiser 3.4 Diesel 80 4×4 – — – 01.1990-12.1996 |
| TOYOTA- -Land Cruiser 3.4 TD- -[13BT]- -10.1985-08.1986 |
| TOYOTA- -Land Cruiser 4.7- -[2UZ-FE]- -01.1998-01.1998 |
| TOYOTA- -Land Cruiser 4.7- -[2UZ-FE]- -01.1999-01.2001 |
| TOYOTA- -Land Cruiser 4.7- -[2UZ-FE]- -01.2002-01.2002 |
| TOYOTA- -Land Cruiser 3.5 80 FRT-Top 4WD- -[1PZ]- -01.1990-08.1992 |
| TOYOTA- -Land Cruiser 4.7- -[2UZ-FE]- -01/02/02 |
| TOYOTA- -Land Cruiser 3.5 FRT-Top 4WD- -[1PZ]- -01.1990-12.1994 |
| TOYOTA- -Land Cruiser 4.7- -[2UZ-FE]- -01/01/03 |
| TOYOTA- -Land Cruiser 3.6 Diesel- -[H]- -04.1979-07.1980 |
| TOYOTA- -Land Cruiser 4.7- -[2UZ-FE]- -01/01/04 |
| TOYOTA- -Land Cruiser 3.9 |
| TOYOTA- -Land Cruiser 2.4 – — – 01/01/87 |
| TOYOTA- -Land Cruiser 4.7- -[2UZ-FE]- -01/01/05 |
| TOYOTA- -Land Cruiser 3.9- -[FJ]- -01/01/72 |
| TOYOTA- -Land Cruiser 4.7- -[2UZ-FE]- -01/01/07 |
| TOYOTA- -Land Cruiser 3.9- -[F] |
| TOYOTA- -Land Cruiser 4.7 90 – — – 01/08/02 |
| TOYOTA- -Land Cruiser 3.9- -[F]- -01.1973-01.1973 |
| TOYOTA- -Land Cruiser 2.4- -[22RE]- -12.1988-12.1996 |
| TOYOTA- -Land Cruiser 4.7 V8 32V- -[2UZ-FE]- -01/01/98 |
| TOYOTA- -Land Cruiser 3.9- -[F]- -01.1974-01.1974 |
| TOYOTA- -Land Cruiser 2.4- -[22R]- -11.1984-05.1993 |
| TOYOTA- -Land Cruiser 5.7- -[3UR-FE]- -01/01/08 |
| TOYOTA- -Land Cruiser 2.4 80 4×4- -[22R]- -01.1990-05.1993 |
| TOYOTA- -Land Cruiser 4.0 – — – 09.2002-08.2004 |
| TOYOTA- -Land Cruiser 2.4 Diesel- -[2L]- -11.1984-10.1985 |
| TOYOTA- -Land Cruiser 4.0- -[1GR-FE]- -01/01/03 |
| TOYOTA- -Land Cruiser 4.0- -[3F-E]- -08.1987-12.1989 |
| TOYOTA- -Land Cruiser 4.0- -[3F-E]- -01.1988-01.1992 |
| TOYOTA- -Land Cruiser 2.4 TD- -[2L-T]- -10.1985-05.1990 |
| TOYOTA- -Land Cruiser 4.0- -[3F-E]- -01.1990-08.1992 |
| TOYOTA- -Land Cruiser 4.0- -[3F]- -11.1984-08.1987 |
| TOYOTA- -Land Cruiser 2.4 TD- -[2L-T]- -01.1990-05.1993 |
| TOYOTA- -Land Cruiser 2.4 TD- -[2L-T]- -07.1990-05.1996 |
| TOYOTA- -Land Cruiser 2.5 TD 4WD – — – 11.1984-12.1989 |
| TOYOTA- -Land Cruiser 2.5 TD 4×4 – — – 11.1984-12.1989 |
| TOYOTA- -Land Cruiser 4.0 Diesel- -[2H]- -08.1980-10.1984 |
| TOYOTA- -Land Cruiser 2.6 Diesel- -[H]- -01.1975-07.1980 |
| TOYOTA- -Land Cruiser 2.7- -[2TR-FE]- -01/11/03 |
| TOYOTA- -Land Cruiser 4.0 Diesel- -[2H]- -10.1981-01.1988 |
| TOYOTA- -Land Cruiser 2.7 90 – — – 04.1995-07.2002 |
| TOYOTA- -Land Cruiser 4.0 Diesel- -[2H]- -01.1982-12.1985 |
| TOYOTA- -Land Cruiser 2.8 TD 4×4- -[3L]- -01.1990-08.2001 |
| TOYOTA- -Land Cruiser 4.0 Diesel- -[2H]- -01.1985-12.1987 |
| TOYOTA- -Land Cruiser 4.0 Diesel 4×4- -[2H]- -08.1987-12.1989 |
| TOYOTA- -Land Cruiser 4.0 TD- -[12HT]- -10.1985-12.1989 |
| TOYOTA- -Land Cruiser 4.0 TD 4×4 – — – 01.1997-08.2001 |
| TOYOTA- -Land Cruiser 3.0 D-4D- -[1KD-FTV]- -01/10/00 |
| TOYOTA- -Land Cruiser 4.2 – — – 01/01/81 |
| TOYOTA- -Land Cruiser 3.0 D-4D- -[1KD-FTV]- -09.2002-02.2010 |
| TOYOTA- -Land Cruiser 4.2 – — – 01/01/82 |
| TOYOTA- -Land Cruiser 3.0 D-4D- -[1KD-FTV]- -01/01/03 |
| TOYOTA- -Land Cruiser 4.2 – — – 01/01/83 |
| TOYOTA- -Land Cruiser 3.0 D-4D- -[1KD-FTV]- -01/08/04 |
| TOYOTA- -Land Cruiser 4.2 – — – 01/01/84 |
| TOYOTA- -Land Cruiser 4.2 – — – 01/01/85 |
| TOYOTA- -Land Cruiser 4.2 – — – 01/01/86 |
| TOYOTA- -Land Cruiser 3.0 Diesel- -[B]- -02.1974-10.1984 |
| TOYOTA- -Land Cruiser 4.2 – — – 01/01/87 |
| TOYOTA- -Land Cruiser 4.2- -[2F]- -01.1975-04.1986 |
| TOYOTA- -Land Cruiser 4.2- -[2F]- -01.1975-01.1977 |
| TOYOTA- -Land Cruiser 4.2- -[2F]- -01.1978-01.1978 |
| TOYOTA- -Land Cruiser 4.2- -[2F]- -01.1979-01.1987 |
| TOYOTA- -Land Cruiser 3.0 TD- -[1KZ-T]- -05.1993-05.1996 |
| TOYOTA- -Land Cruiser 4.2- -[2F]- -10.1981-01.1988 |
| TOYOTA- -Land Cruiser 3.0 TD 4WD- -[1KZ-TE]- -01/04/96 |
| TOYOTA- -Land Cruiser 3.0 TD 90- -[1KZ-TE]- -04.1995-07.2000 |
| TOYOTA- -Land Cruiser 4.2 Diesel- -[1H-Z]- -01.1990-12.1997 |
